M10 4 Post Heavy Duty 48V 600 Amp Bus Bar

Regular price $85.00 AUD
Colour

Delivering Outside Australia or New Zealand? Delivery is free. Import duty, customs charges and any tax on arrival are set by your country and are payable by you — we can’t collect them for you.

Tracking

Keep an Eye on your Gear

Simply enter the tracking number sent to your email to see exactly where your package is and when it is estimated to arrive.

Note: It may take 24-48 hours for tracking information to update after your order has been dispatched.

Track my Order

One Clean Landing Point for Four Heavy Cables.

Every 48V build reaches the same moment. The controller, the inverter, the battery bank and a couple of loads all want to meet in one place, so they end up stacked on a battery post — three lugs under one nut, none of them torqued properly. It works until a corrugated road shakes one loose. Then you are on your back under the canopy with a torch, chasing a joint that has gone warm.

This is a four-post bus bar with M10 studs, rated by the supplier at 600A continuous DC, under a removable fire-resistant nylon cover. Four heavy cables land on their own stud, each one torqued to a stated figure, with the cover back on so a dropped spanner cannot bridge two of them.

Before you order — you get ONE bus bar, not two. The supplier's own packaging photographs read 1PCS RED and 1PCS BLACK, and the colour dropdown on this page is a choice between the two, not a set. If you want a positive and a negative, put two in the cart: one red, one black. The word "pair" in this page's web address is left over from an older listing and it is wrong. The 400A and 500A bus bars in our range do ship as positive-and-negative sets — this one does not.

This is a 48V DC product. BushLine stocks 48V bus bars on purpose — the cheap 12V and 24V blocks are easy to find anywhere and we do not sell them.

What it Solves
  • No More Stacked Lugs on a Battery Post: three heavy cables under one nut is how you get a hot joint. Land them here and the battery post carries one clean connection.
  • A Torque Figure you can Work to: the supplier states 15.8 Nm on the studs, so you can set a wrench instead of guessing and stripping an M10 thread.
  • Nothing Shorts Across the Studs: the cover clips over the terminals, which matters in a battery box or an engine bay where tools get put down in odd places.
  • Room for the Load you Add Next: four posts means the next inverter or winch circuit has somewhere to go without rebuilding the run.
Key Features
  • 600A Continuous DC: the supplier's rating. Read the honest note on conductor thickness in the Q & A before you size a system around it.
  • Four M10 Studs: on 31 mm centres, so four heavy ring lugs sit side by side without fouling each other.
  • Stud Torque Stated: 15.8 Nm. Over-tightening an M10 stud on a bus bar is a real way to ruin one.
  • Nickel-Plated Copper Studs: supplier stated. Plating is what keeps a joint from going green and then going hot.
  • Fire-Resistant Nylon Base & Cover: supplier stated. No flammability class is published, so we do not quote one.
  • Removable Cover: moulded cut-outs let the cables out the front while the terminals stay covered.
  • Compact Footprint: 178 x 51 mm base, 50 mm tall, so it fits a battery box lid or a bulkhead.
  • Mounting Screws in the Box: ten self-tapping screws are shown supplied with each unit, four base holes to fix it down.
  • Red or Black: pick the colour that matches the side you are wiring — one unit per order.
What Else you'll Need

A bus bar distributes power. It does not protect anything, and on its own it is half a job. Here is what usually goes around it:

What we do Not Cover for you: cable sizing. It depends on your run length, your voltage and your actual current draw, and nobody can size it for you from a product page. Work it out against your own run or ask your sparky. If you are building 12V or 24V rather than 48V, the sizing changes again and this is not the bus bar we would point you at.

Technical electrical equipment — turbines, controllers and distribution gear like this — should be installed by a qualified person. Keep the electrician's invoice: our returns position on electrical goods asks for proof of professional installation.

Q & A

Do I Get One Bus Bar or Two?
One. The supplier's packaging images say 1PCS RED and 1PCS BLACK, and the only option on this page is that colour choice. Order two if you need a positive and a negative. We know the web address says "pair" — it is an old handle and it is wrong.

What Torque do the M10 Studs Take?
The supplier states 15.8 Nm. Work to that. A bus bar stud that has been leaned on with a long spanner either strips or distorts the bar, and neither shows up until the joint gets hot under load.

The Studs are Marked M10 and Also 3/8-16. Which is it?
Both markings appear on the supplier's own drawing, and they are not the same thread — 3/8 inch is 9.5 mm, M10 is 10 mm. The store sells it as M10 and the option list says M10. Either will pass through a 10 mm ring lug hole, so for lugs it makes no practical difference. If you intend to run your own nut onto a stud, check the thread on arrival before you buy hardware for it.

How Thick is the Conductor Bar, and is 600A Real?
Not specified by supplier. That is the honest answer and it matters, because conductor cross-section is what actually sets a current rating — not the number printed on the box. 600A continuous DC is the supplier's figure and we have not seen a conductor size behind it. Our 400A bus bar publishes 8 mm tinned copper and the 500A publishes 6 mm pure copper; this one publishes nothing. Size your system on your cable and your breakers, and treat the 600A as headroom rather than a design limit.

The Supplier's Drawing Also Shows AC Figures. Do they Apply?
The drawing prints 300V AC and 545A AC alongside the DC ratings. We sell and rate this as a 48V DC part and no certificate has been sighted for the AC figures. If you need a mains-voltage AC rating, this is not the part.

Can I Use it on a 12V or 24V System?
Electrically it will work below its rating, so nothing stops you. But we stock 48V bus bars deliberately — the cheap 12V and 24V blocks are available anywhere and this is priced as a 48V part. If you are building 12V, buy accordingly and check your cable sizing for that voltage, because the currents are much higher for the same power.

Does it Come with a Fuse or Breaker, and is it Waterproof?
No to both. A bus bar distributes, it does not protect — you still need a breaker or isolator on each circuit and a main battery breaker. No ingress rating is specified by supplier. The cover keeps fingers, spanners and falling debris off the terminals; do not treat it as sealed, and do not mount it where it will sit in water.

Specs

Product Type DC Power Distribution Bus bar, Four Post
Supplied as ONE bus bar per order — red or black, chosen at checkout. Not a positive-and-negative pair
Max Continuous Current 600A DC (Supplier Stated)
System Voltage 48V DC
AC Figures on the Supplier Drawing 300V AC / 545A AC also printed. Sold and rated here as a 48V DC part — no certificate sighted for the AC figures
Terminal Studs 4 x M10
Stud Thread Marking Supplier drawing prints both "M10" and "3/8-16" (9.5 mm). Check the thread before buying loose nuts
Stud Spacing 31 mm Between Centres
Stud Torque 15.8 Nm (Supplier Stated)
Stud Material Nickel-Plated Copper (Supplier Stated)
Conductor Bar Material Not Specified by Supplier
Conductor Thickness / Cross-Section Not specified by supplier — this is what sets a real current rating, so treat the 600A figure accordingly
Conductor Plating Not Specified by Supplier
Cable Size Compatibility Not specified by supplier — set by the M10 ring lug that fits
Base & Cover Material Fire-resistant nylon (supplier stated). No flammability class specified by supplier
Cover Removable, with Moulded Cable Cut-Outs Over the Studs
Base Footprint 178 x 51 mm
Cover Length 182 mm
Overall Height 50 mm
Base Thickness 17 mm
Mounting Four base holes; ten self-tapping screws shown supplied with each unit
Auxiliary Screw Terminals Small screw terminals sit at the ends of the bar. Count and rating not specified by supplier
Colours Red or Black — One Colour per Order
Ingress Rating Not Specified by Supplier
Weight Not Specified by Supplier
Circuit Protection None Included — Fit your Own Breakers & Isolators
Applications 48V off-grid solar and wind, battery banks, marine, RV, truck, 4x4
