48V DC 400A Power Bus Bar M8 & M10 Set
Tracking
Tracking
Keep an eye on your gear.
Simply enter the tracking number sent to your email to see exactly where your package is and when it is estimated to arrive.
Note: It may take 24-48 hours for tracking information to update after your order has been dispatched.
Delivery and Shipping
Delivery and Shipping
At Bushline, we believe getting your gear should be easy. That is why we offer Free Standard Shipping to every customer in Australia and New Zealand. No minimum spend, no surcharges.
How Long It Takes
We quote these times from the day you place your order, not from the day we dispatch it. That is the number that actually matters to you, and quoting it any other way just moves the goalposts.
- Most gear: 10 to 14 days from the day you order. Allow up to 3 weeks.
- New Zealand: Same as above. NZ orders run to the same timeframe as Australian ones.
- Large wind turbines: Allow up to 5 weeks. These are heavy, oversized units and they travel on slower freight than everything else.
- Regional & remote areas: Please allow extra time on top of the above.
Dispatch & Tracking
- Pick & Pack: We aim to dispatch within one business day (Monday to Friday). Most orders go out within two.
- Weekends: Orders placed on weekends or public holidays are processed the next business day.
- Tracking: You will get a Shipping Confirmation email with your tracking number as soon as your order ships.
If Your Order Is Running Late
Ring 0400 333 898 or email Support@BushLine.com.au and we will chase the tracking ourselves rather than sending you off to do it. You will get a straight answer on where it is, including if it has not moved.
Need A Large Turbine Sooner?
Expedited freight is available on the big units at extra cost, which brings delivery down to roughly a fortnight. It is quoted per order because it depends on the size of the unit and where it is going. Get in touch before you order and we will price it for you.
Wire your controller to your battery through this.
Everything in an off-grid system has to land somewhere before it reaches the battery — turbine, solar, inverter, loads. That is the job of a bus bar, and it is the part people under-buy, because from the outside a cheap one looks the same as a good one. Plenty sold online are undersized parts with a big number printed on them.
This is a 400A pair, positive and negative, on 8 mm tinned copper plate with M8 and M10 studs. Tinning is what stops the copper corroding, which is why it suits marine and coastal setups as well as a shed.
Straight up on sizing: for a 48V bank, the right bus bar depends on your actual current draw and how much voltage drop you are willing to wear. A common rule of thumb is at least 300A, and thicker and wider always means less voltage drop and less heat. If you are not sure what your system pulls, work it out or ask your sparky before you buy — this is not the part to guess on.
Key Features
- 400A rating: heavy-duty positive and negative pair, sized for 48V DC systems.
- 8 mm tinned copper plate: high conductivity, and the tinning resists corrosion so it lasts in marine and coastal air.
- M8 and M10 studs: takes the lug sizes you will actually be crimping onto heavy cable.
- Holds its torque: the block and base are fixed so the copper bar does not work loose under load.
- Protective cover: shields the exposed terminals against accidental contact and shorts, and still allows multi-angle mounting.
- Red and black pair: keeps positive and negative clearly separated — tidier wiring, less chance of a short or a hot joint.
- Six configurations: M8 or M10, in 3 or 4 post, with 3, 6, 8 or 10 screw terminals.
What It Solves
- No more stacked lugs on a battery post: three heavy cables on one terminal is how you get a hot joint. Land them here and the battery post carries one clean connection.
- Corrosion resistance that matters near salt: bare copper goes green and green joints go hot. The tinning is the difference on a boat or a coastal block.
- Find a fault fast: when every connection meets in one labelled place, checking them is a five-minute job instead of tracing cable through a canopy.
- Room for the gear you add later: pick a configuration with spare screw terminals and the next load has somewhere to go.
- Covered terminals in a working space: the cover stops a dropped spanner shorting across the studs.
Where This Fits
A bus bar is one part of the gear that sits between a wind turbine and your battery bank. Here is the whole picture:
- Wind turbines: vertical axis turbines from 1kW to 20kW — quiet enough to put near the house, and they charge overnight when your solar cannot.
- Hybrid MPPT controllers: you cannot wire a turbine straight to a battery. The controller rectifies the output, manages the charge, and brakes the turbine when the bank is full.
- The rest of the electrical range: breakers, isolators, cable, lugs and Anderson plugs.
Every input and output wants a breaker or isolator on it, so you can safely shut down and isolate the turbine before you touch anything. That protects you, and it stops a surge damaging your new turbine or the rest of your power system. Cable sizing depends on run length, voltage and current — check it against your own run or ask your sparky, and keep the invoice, because our warranty on electrical items asks for proof of professional installation.
Q & A
Which configuration should I pick?
Match the stud size to the lugs you are crimping — M8 or M10 — then count the connections you need now and add a couple of spares. Options run from 3 screw terminals up to 10. It is cheaper to buy spare terminals than to buy a second bus bar in six months.
400A or the 500A model?
Work out your actual peak draw first. A rule of thumb for a 48V bank is at least 300A, so 400A suits most builds with headroom. Step up to the 500A if you are running a big inverter and a winch or similar at the same time, or if you want the extra margin.
Can I use it on a 12V or 24V system?
Electrically it will work below its rating. But BushLine stocks 48V bus bars on purpose — the cheap 12V and 24V blocks are available anywhere and this is priced as a 48V part.
What does the "300V AC" figure mean?
That comes from the supplier and we print it as given. Treat this as a 48V DC product. We have not sighted a certificate behind the AC figure, and an AC rating is not something to design around on a DC distribution block. If you need a mains-voltage AC rating, this is not the part.
Does it come with circuit protection?
No. A bus bar distributes, it does not protect. You still need a breaker or isolator on each circuit and a main battery breaker.
Specs
| Product type | DC power distribution bus bar. Positive and negative pair |
| Current rating | 400A |
| System voltage | 48V DC |
| Voltage row as supplied | Supplier states "48V DC / 300V AC". Treat as a 48V DC product — no certificate sighted for the AC figure |
| Conductor | 8 mm tinned copper plate |
| Stud sizes | M8 or M10, depending on option |
| Configurations | M8 4 post 3 screw · M10 4 post 3 screw · M8 4 post 6 screw · M10 4 post 6 screw · M8 3 post 10 screw · M10 4 post 8 screw |
| Connection type | Screw / ring terminal |
| Cable size compatibility | Not specified by supplier — set by the M8 / M10 lug that fits |
| Corrosion protection | Tinned copper |
| Cover | Protective cover over the terminals, multi-angle mounting |
| Colours | Red (positive) and black (negative) pair |
| Ingress rating | Not specified by supplier |
| Dimensions | Not specified by supplier |
| Weight | Not specified by supplier |
| Circuit protection | None included — fit your own breakers and isolators |
| Applications | 48V off-grid solar and wind, marine, boat, yacht, RV, 4x4 |
Watch Me
No video on this one. If you are wiring an off-grid system, these two guides cover the sequence and the hazards:
- How to install and start up a wind turbine — the correct order of connection, and the two shock hazards to know first.
- Wind turbine spinning but showing 0W — nearly always wiring or setup rather than faulty gear.
